SL42STH-48-2004A Nema17 59Ncm 2A 1.8°4-lead 48mm Stepper Motor For 3D Printer CNC

Specifications: – Material: Metal – Dimensions: 42x42x48mm/1.65”x1.65”x1.88” – Phase Number: 2 – Step Angle: 1.8°±5% – Rated Voltage: 2.8V – Holding Torque: ≧5 Kg-cm(70 Oz-in) – Rated Current: 2.0A – Resistance(20℃): 1.4±10%?/phase – Max. Slewing PPS: 2500 PPS – HI-POT: AC 600V/1mA/1S – Rotor Inertia: 68g.cm2 – Inductance: 3.0±20%mH – Detent Torque: 2.0Kg-cm – Insulation Resistance: ≧100M?(DC 500V) – Leads: 4 – Application: Use for3D printer, Linear actuators and CNC router for plastic&metal. Note: *Please allow a little difference due to manual measurement. Package Included: 1 x Stepper Motor SKU: N/A Categories: 3D Accessories, 3D Printing, Stepper motor
